Defence & Security

Phase2 Microwave works with the major European Miltary groups including Airbus, Selex, BAE System and Thales to provide a wide range of microwave components and subsystems.




q1004 space diplexer honeywell 3Defence & Security



Phase2 Microwave works with the major European Military groups including Airbus, Selex, BAE System and Thales to provide a wide range of microwave components and subsystems.

 We have the ability not only to provide high performing components but also to work with the project team, using 3D cad, and being involved with the system design, to provide the optimum electrical and mechanical solution.

Examples include work on various Naval Satcoms systems and S Band Radar Tx-Rx modules.



Recent Projects



A range of low loss coaxial GPS notch filters are available with notch rejection up to 80dB.

They are an essential component of high power anti-IED jamming systems.



 q1233 gps notch 2



Products, Service & Capabilities



Mil-Satcoms

A range of low loss waveguide filters is available for X Band and Ka Band

An example of a high power X Band Mil-satcoms switched filtering system is shown below.



 GPS Notch Filters

A range of low loss coaxial GPS notch filters are available with notch rejection up to 80dB.

They are an essential component of high power anti-IED jamming systems.



UHF Communication Filters and Diplexers.

Phase2 Microwave provide coaxial and Helical filters solutions for the military in the UHF band.



EW Filters

Narrowband and wideband ( up to 40%) coaxial filters can be designed exactly using in house software and mode-matching programs together with high performing lowpass filters.



Specialised Components

Because of our extensive microwave experience and EM and mechanical modelling capability we can provide special variations of standard components, such as transitions or couplers, with special interfaces, shapes or performance.

We have the ability not only to provide high performing components but also to work with the project team, using 3D cad, and being involved with the system design, to provide the optimum electrical and mechanical solution. Examples include work on various Naval Satcoms systems and S Band Radar Tx-Rx modules.



MilSatcoms

A range of lowloss waveguide filters is available for X Band and Ka Band.



ATC Cavites and Combiners

Air Traffic Control applications (both Civil and Military) lie between 118 and 400Mhz and use narrowband comms channels. Phase2 Microwave have developed high Q highly temperature stable cavities which can be operator set at any frequency in the VHF band. The terchnology can also be used for the UHF band. The cavities can be cable combined to form combiners.









Case Studies



  q659 spectrum 3

Q525 - S Band Radar Receive Filter



The system specification calls for more rejection than normal
for the receive filter, in order to attenuate 4G base station signals
which can now transmit up to 2.7GHz.

Q525 Case Study - Read Me
